Fantom Concealed Magnetic Door Stop
Couldn't load pickup availability
Description
Description
Introducing the Fantom Concealed Magnetic Door Stop, the perfect addition to any project. This innovative system not only offers a hold-open function, but also eliminates tripping hazards while maintaining a sleek and luxurious finish. Say goodbye to bulky door stops and hello to a high-quality solution that meets all your application requirements.
- Wood Door application only.
- Fully concealed magnetic door stop that includes a hold-open function.
- The recommended gap between the floor and the bottom of the door should be a minimum of 3/16" and a maximum of 19/32".
- Meets ADA less than 5 lbs. of force to open.
- Typical force required to release a single Fantom stop is 2.72 lbs.
- Concealed rare-earth magnet technology ensures exceptional mechanical functionality.
- Fasteners provided: 2ea #8 x 1" Stainless Steel screws.
- Can be used with low-pile carpet (not advised for use with deep carpet.)
- Should not be used for outdoor use.
- Works on larger doors as well as normal-sized doors.
- Works best without a door closer.
- Double Doors: For interior double doors, the Fantom can be used in place of flush bolts or surface bolts. Install in the floor and header of the fixed door.
- See Downloads for installation outline and specs.
Specifications
- Base Diameter: 1-3/32"
- Bolt Length: 1-3/4"
- Base Width: 1-11/16"
- Pin Height: 3/8"
- Magnet Diameter: 15/16"
- Magnet Height: 19/32"
- Strike Plate Length: 3-5/32"
- Strike Plate Width: 1-5/16"
