Toy Box Lid Supports, Weight Rated
Couldn't load pickup availability
Description
Description
- Recommended for toy chests, cedar chests, blanket chests, etc.
- Screws are NOT included. Order our sku #286252
- Toy box lid support self-balancing feature holds lid in any position to about 85 degrees.
- This toy chest hardware is used in conjunction with hinges (or a piano hinge), these lid supports counterbalance the lid to keep it from slamming shut.
-
FORMULA: To calculate the inch/pound rating of your lid multiply 1/2 the front to back lid distance (in inches) times the lid weight (in pounds).
- It is always best to actually weigh your lid on a scale. However, if this is not possible and your lid is made from plywood, you can use the following to calculate the approximate weight of your lid; 3/4" thick plywood weighs about 2.34 lbs. per square foot.
- For inch/pound ratings over 140 use more than one lid support (do not combine lid supports of different ratings).
- If you use two lids supports on one lid, the combined inch/lbs rating of the two supports should equal the inch/lbs calculation for your lid.
- This product complies with the CPSC's voluntary standards.
- For this toy chest hardware to work properly it is important that you use the simple formula shown above to calculate the "torque" or "moment" that your lid creates as it pivots on its hinges. It is a combination of the weight of the lid and the front to back dimension of the lid.
- We get a lot of customers who ask, "Should I go to a heavier rated support to be safe? The answer isno. Get a precise weight on your lid, do the calculation and use a lid support that fits in between the recommended weight rating range.
- If you are using more than one lid support and you are questioning whether you should use 2 supports that are at a heavier rating or 3 supports that are at a lesser rating, the answer is that you should choose the configuration that calculates out closest to the middle of the rating range.
- If you need help with the calculation email us the exact weight of your lid (in pounds) and the front to back dimension of your lid (in inches) and we will do the calculation for you. We will email you back the correct items for you to order.
- The maximum back wall thickness that this toy box lid support will work with is 3/4".
- The spring colors are shown to help identify the different weight ratings of the lid supports.
Store Policies & Information
Store Policies & Information
Shipping & Delivery
Returns
Contact Us
We have been selling hardware and hinges for over 130 years. When you shop with us, you can count on prompt, personal customer service and reliable support.
Page Code: C10168
-
Finish Name
-
MaterialSteel
-
Opening Angle85 Degrees
-
Mounting Hardware Included
-
Mounting Hardware Type
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Customer Reviews
The lid supports work just fine. My only issue with the order is that I did not get installation instructions with the supports. The location of the supports is critical. I did get the instructions after emailing one of your employees.
I calculated the weight of the lid for the box I made of 3/4" plywood, using the figures supplied. I obviously got it wrong since the spring was too light. A telephone assistant asked for the dimensions of the lid and told me which lid support to order. I ordered it, and it turns out to be a bijt too strong. The lid doesn't close all the way. I hope it will loosen up gradually or someone will put, say, a cushion on top of the box. At least the lid won't slam down.
Toy Box Lid Supports, Weight Rated
I had to replace my lid Support for a chest that is made of solid oak. I couldn’t find one locally. And found Hardware Source and they helped me pick the right lid Supports for a solid oak lid weight of 16 lbs 5 ounces. They had my use 2 with the yellow spring. Worked Better than the single one that was on there for 20+ years.
Thanks Again
